SM 031, 1/3-phase, 230/400V, 1A

Изделие: 031-1PA00

Краткое описание:

Модуль аналогового ввода, измерение параметров 1/3-фазной электрической сети, 24 разряда

Производитель: VIPA
Вес: 0.1 кг.

Розничная цена: 99051

БЫСТРЫЙ ЗАКАЗ

SM 031 031-1PA00

Модуль аналогового ввода, измерение параметров 1/3-фазной электрической сети, 24 разряда

Наименование	Модуль аналоговых входов SM 031, 1/3-phase, 230/400V, 1A
Тип	031-1PA00
Габаритные размеры, В х Ш х Г, мм	12.9 mm x 109 mm x 76.5 mm
Температура окружающей среды	0 °C ... 60 °C

Locking lever terminal module
Labeling strip
Backplane bus
LED status indication
DC 24V power section supply
Electronic module
Terminal module
Locking lever electronic module
Terminal

Status indication

RUN	MF	Description
green	red
●	○	Bus communication is OK Module status is OK
●	●	Bus communication is OK Module status reports an error
○	●	Bus communication is not possible Module status reports an error
○	○	Error at bus power supply
X	B	Error in configuration
on: ● \| off: ○ \| blinking: B \| not relevant: X

>U	red	○	Voltage in the parametrized range
		●	Voltage limit value exceeded
<U	red	○	Voltage in the parametrized range
		●	Voltage limit value undershot (omitted in 1-phase operation)
>I	red	○	Current in the parametrized range
		●	Current limit value exceeded
<cos	red	○	Phase shift cos j in the parametrized range
		●	Phase shift cos j limit value undershot (omitted in 1-phase operation)
TEMP	red	○	Temperature in the parametrized range
		●	Temperature limit value exceeded
P	green	B	P: Power-proportional blinks with increasing frequency proportional to the active power at 20 pulses/Wh. The current transformer factor is not considered.
on: ● \| off: ○ \| blinking: B \| not relevant: X

Pin assignment

PM - Power module	Pos.	Function	Type	Description
	1	L1	I	Voltage measurement L1
	2	L2	I	Voltage measurement L2
	3	L3	I	Voltage measurement L3
	4	N	I	Voltage measurement N
	5	I_L1	I	Current measurement I_L1
	6	I_L2	I	Current measurement I_L2
	7	I_L3	I	Current measurement I_L3
	8	I_N	I	Current measurement I_N

I: Input

Order no.	031-1PA00
Type	SM 031
Module ID	0882 2880
General information
Note	-
Features	1/3 phase 230/400V 1A Resolution measured value
Current consumption/power loss
Current consumption from backplane bus	60 mA
Power loss	0.9 W
Rated load voltage	-
Status information, alarms, diagnostics
Status display	yes
Interrupts	yes, parameterizable
Process alarm	no
Diagnostic interrupt	no
Diagnostic functions	yes, parameterizable
Diagnostics information read-out	possible
Module state	green LED
Module error display	red LED
Channel error display	-
Isolation
Between channels	-
Insulation tested with	AC 2200 V
Energy measurement
Number of channels for measuring	1* 1..3 phases U/I
Voltage measuring range	0..300 V each phase
Coupling voltage measurement	directly
Current range	-
Coupling current measurement	Transformer
Frequency range	46...64 Hz
Measurement accuracy	1 %
Available measurement	Active energy Temperature Frequency Voltage RMS Current RMS Active power Reactive power Apparent power Cos phi Harmonic voltage RMS Harmonic current RMS
Adjustable limits	Voltage RMS min/max Current RMS min/max Cos phi min Temperature max. Frequency min/max
Datasizes
Input bytes	16
Output bytes	16
Parameter bytes	28
Diagnostic bytes	20
Housing
Material	PPE / PPE GF10
Mounting	Profile rail 35 mm
Mechanical data
Dimensions (WxHxD)	12.9 mm x 109 mm x 76.5 mm
Net weight	60 g
Weight including accessories	-
Gross weight	-
Environmental conditions
Operating temperature	0 °C to 60 °C
Storage temperature	-25 °C to 70 °C
Certifications
UL certification	-
KC certification	-
